High-temperature 80V/3A dual-diodes target general apps



CISSOID, a leader in high-temperature semiconductor solutions, expands its PLANET family of discrete products with the launch of CHT-AMALTHEA, a medium power, general purpose, dual diode in a hermetically sealed metal can TO-257 package. This new device is guaranteed for operation from -55°C up to +225°C. CHT-AMALTHEA includes two diodes and is available in three possible configurations: Common anode, common cathode and dual series configurations. Each diode has a reverse voltage of 80V, a maximum forward current of 3A DC and 4A peak at 225°C, making them suitable for a number of power applications. The metal, TO257 package is isolated from the pins, facilitating the mechanical assembling of the systems. This dual diode is a general purpose, discrete component that can be used in a variety of medium power applications, including rectification, free-wheeling, clamping and sensing, among others. CHT-AMALTHEA diodes present a junction capacitance of 36pF and 56pF at 20V and 80V reverse voltages respectively. A rectifier bridge can easily be implemented by using two AMALTHEA. Each diode has a forward voltage of 1.53V typ. at 225°C (and at 2A forward current) and presents a very low leakage current of 15μA at 80V reverse voltage and at 225°C. A product datasheet is available now from CISSOID's website (Link to datasheet). CHT-AMALTHEA can be ordered for sampling and evaluation under the part number CHT-PLA0738x-TO257-T. Pricing starts at 134.19€ for 51 to 200 units. CISSOID
