High-Voltage Cartridge Fuse Features AEC-Q200 Compliant Overcurrent Protection


Ideal for on-board chargers and power distribution units in electric vehicles

Littelfuse, Inc. announced the new 828 Series High-Voltage Cartridge Fuses, designed and tested to meet the circuit protection needs of compact automotive electronics, specifically Electric Vehicle (EV) applications.

These robust fuses are Littelfuse internal AEC-Q200 compliant, providing a high interrupting rating (10 KA @ 1,000 Vdc), which is ideal for the On-Board Chargers (OBCs) and Power Distribution Units (PDUs) in the latest EV designs. Available in through-hole and bolt-down versions, it’s flexible for either printed circuit board (PCB) or screw-in assemblies.

The 828 series fuse offers these key benefits:

  • AEC-Q200 compliant, compact 10 x 38 mm cartridge fuse with very high interrupting rating (10 KA @ 1,000 Vdc) provides superior overcurrent protection for automotive EV designs.

  • End caps with integrated stand-off leads and bolt-down options eliminate the need for mounting accessories or lead-forming processes.

  • Operating temperature range from -55˚C to 125˚C provides reliable protection in extreme temperature environments.

  • Environmentally-friendly component is RoHS compliant, halogen-free, and 100% Pb free.


The 828 series fuse is provided in tray package of 500 for through-hole version and 300 for bolt-down version.
