    II-VI Advanced Materials claims first 200mm SiC wafer

    07/20/2015

    II-VI Advanced Materials, a leading supplier of
    single crystal SiC (silicon carbide) substrates and CVD-grown
    polycrystalline diamond materials, recently exhibited the world's first
    200mm diameter SiC wafer at the 2015 Compound Semiconductor
    Manufacturing Technology (CS MANTECH) conference in Scottsdale, AZ and
    the International SiC Power Electronics Applications Workshop
    (ISiCPEAW) in Stockholm, Sweden.

    Dr. Thomas Anderson, General Manager of II-VI Advanced Materials said,
    "This achievement is a direct result of our consistent focus on
    providing the market with leading-edge quality substrates at the
    diameters required to enable more cost effective semiconductor device
    manufacturing. The earlier introduction of our 150mm diameter SiC
    substrates was extremely well received by our customers, and
    significant growth in the demand reflects market recognition of the
    improved economics of SiC device manufacturing at increased diameters.
    Devices built on these substrates will be or are currently being
    utilized in a wide range of applications requiring high power density
    and system efficiency, such as electric vehicles, inverters for PV
    solar energy and other renewable energy installations."

    This development program builds upon years of work funded, in part, by
    the U.S. Air Force Research Laboratory (AFRL). It focused on the
    manufacturing scale-up of the II-VI Advanced Physical Vapor Transport
    (APVT) SiC crystal growth technology as well as the development of
    state-of-the-art fabrication, polishing and cleaning processes. These
    efforts have resulted in achievement of world-class quality material
    while at the same time increasing the diameter from 3" to 100mm, then
    to 150mm and now to the world's first 200mm SiC substrates.

    "This 200mm SiC wafer demonstrates our market leading crystal growth
    and fabrication technologies, as well as our commitment to respond to
    and work with our customers to ensure a smooth transition to the next
    generation of substrates. We are dedicated to pushing the boundaries of
    SiC substrate technology to ensure that the market has the material it
    needs to make high performance SiC based devices both cost effective
    and widely utilized," commented Dr. Andrew Souzis, Director of Business
    Development.
