Low-noise low-dropout 600mA negative linear regulator includes precision programmable current limit and bidirectional output current monitoring

Date
10/14/2013

 PDF

Linear Technology announced the LT3090, the latest member of their LDO+™ family, a 600mA low dropout negative linear regulator featuring low noise, rail-to-rail operation, precision programmable current limit and a bidirectional output current monitor. The device is cable-drop compensation capable, easily parallelable for higher current or PCB heat spreading and configurable as a floating 3-terminal regulator. The LT3090's input voltage range is -1.5V to -36V. A single resistor programs the adjustable rail-to-rail output voltage from 0V to -32V and dropout voltage is only 300mV (typical at full load). The device features a trimmed, 1% accurate 50μA current source reference and provides 2% output voltage tolerance over line, load and temperature. Output voltage regulation, bandwidth, transient response and output noise (18μVrms over a 10Hz to 100kHz bandwidth) remain independent of output voltage due to the device's unity-gain voltage follower architecture. The LT3090 is ideal for negative logic supplies, low noise instrumentation and RF supplies, rugged industrial supplies and for post-regulating switching supplies. The LT3090 exhibits excellent stability with a wide range of output capacitors including small, low cost ceramic capacitors. It is stable with a minimum 4.7μF output capacitor. A single resistor adjusts the precision programmable current limit. The device's bipolar current monitor either sources or sinks a current proportional to output current, useful for system monitoring. The LT3090's bidirectional shutdown capability allows the device to operate with either positive or negative logic levels. In addition, the LT3090's accurate shutdown thresholds enable a programmable UVLO threshold for either the regulator's input supply or a positive system supply voltage. Internal protection circuitry for the IC includes a precision current limit with foldback and thermal shutdown with hysteresis. In bipolar supply applications where the regulator's load returns to a positive supply, the OUT pin can be pulled above GND up to 40V and will still allow the LT3090 to safely start up. The LT3090 is available in a low profile (0.75mm) 3mm x 3mm 10-lead DFN and a 12-lead MSOP package, both with backside thermal pads. E- and I-grade operating junction temperature is -40°C to +125°C, H-grade is -40°C to +150°C, and the MP-grade is specified over the widest operating range from -55°C to +150°C. 1000-piece pricing for the E-grade version starts at $2.15 each, and devices are available from stock. Linear Technology
