Powering Embedded Systems

June 2019

3W Ultra-thin Isolated Regulated Output DC/DC Converters

The new series URB/VRB-J(M)D/T-3W provides 4:1 and 2:1 ultra wide input range, features 1500VDC isolation voltage, and delivers efficiencies up to 83%. Packages are available in SMD and DIP. In addition to meeting EN62368 standards, protections for input under-voltage, over voltage, over-current, output short cir

. . . Learn More

Date:

06/17/2019

HARTING and HIROSE push infrastructure for Single Pair Ethernet

To make the new connection technology for Single Pair Ethernet a success, the technology partnership is pursuing the systematic expansion of SPE to achieve an end-to-end, complete infrastructure. This infrastructure consists of a portfolio of connectors, sockets, cables and cable sets on the component side. In

. . . Learn More

Date:

06/06/2019

Rad-Hard 16-Channel Current Driver with Integrated Decoder

The ISL72814SEH integrates the decoder, input level shifter, and 16 current driver arrays in a single monolithic IC. The device allows satellite manufacturers to significantly increase system capacity and cut solution footprint by 50 percent for their medium Earth orbit (MEO), geosynchronous Earth orbit (GEO), h

. . . Learn More

Date:

06/06/2019

Encapsulated sixteenth-brick DC-DC converters

The modules are housed in the industry-standard sixteenth-brick form factor (35.3 x 25 x 10.4mm / 1.39 x 0.984 x 0.41 in), with sealed and encapsulated packaging. This ensures their reliability when exposed to dust, moisture, severe vibration and other harsh environmental conditions. There are two variants: the PKU35

. . . Learn More

Date:

06/06/2019

Powerbox announces 105 models of DC/DC converters featuring 2xMOPP medical approvals

The PMM15, PMM20 and PMM30 are certified to the 3rd Edition of the IEC/EN/ANSI/AAMI ES 60601-1 medical safety standard and rated for the highest levels of patient protection - 2xMOPP. With a clearance and creepage distance of 8mm, a typical leakage current of 2µA and a 5,000VAC isolation voltage, the modules ensur

. . . Learn More

Date:

06/06/2019

New angled locking cable for IEC C14 Power Connectors

The newest connector in the IL13 family sets a benchmark in space limited locking situations. Due to its angled construction the connector can be beneficially used with devices standing next to a wall or in table-top applications. The connector comes in four different orientations to cater for any assem

. . . Learn More

Date:

06/06/2019

Now at Mouser: Maxim’s MAX77860 Switch-Mode Buck Charger

The MAX77860 is ideal for USB Type-C charging for single-cell (1S) lithium-ion or lithium-polymer applications, portable medical equipment, portable industrial equipment, and mobile point-of-sale devices, as well as smartphones and Internet of Things (IoT) applications. The Maxim MAX77860 step-down charger, available from

. . . Learn More

Date:

06/06/2019

10W reed relay suits high-PCB-density applications

Series 122 relays measure 12.5mm in height and are rated with a switching current of 0.5A at 10W. 3V and 5V coils are available. Fast operate and release times, typically 150 μs or less, make Series 122 relays ideal for high speed test systems such as A.T.E. switching matrices or multiplexers.

. . . Learn More

Date:

06/06/2019
