How electrification is transforming cable design and performance across the aerospace and defence industries
The electrification of aerospace and defence is a complete rethinking of flight. From advanced electric propulsion systems to digitally interconnected power networks, every cable, connector and material choice now carries the weight of performance, safety and sustainability. The drive to reduce emissions and improve efficiency has shifted the sector’s engineering priorities toward lighter, smarter and more electrified systems.
At the heart of the electrification shift lies the electrical system, the nervous system of the aircraft. Where mechanical and hydraulic components once dominated, high-voltage distribution and intelligent power management now take the lead.
The challenge is monumental, designing cabling systems that can transmit greater power through smaller footprints, resist extreme altitudes and temperatures and integrate seamlessly with next-generation avionics and propulsion technologies.
Electrification is a structural change in how aircraft distribute and manage energy. Conventional commercial aircraft rely on 115 volts alternating current (V AC) at 400 Hz as the primary power source onboard, with 28 volts direct current (V DC) supplied through transformer rectifier units to support lower power subsystems like avionics or lighting. As electrification adds more power demands on propulsion, these legacy voltage levels require cable systems that deliver greater levels of power both safely and reliably.
However, as power density increases, the margin for insulation error shrinks. This means that the wiring architecture must not only carry more current but also do so safely in environments where stressors, like temperature and vibration, amplify electrical stress.
Designing for power and precision
Electrification demands a new approach to how aerospace and defence engineers design and specify cabling. Modern systems must handle higher voltages without adding excess weight, a balance achieved through advanced materials and smarter design methodologies.
Fluoropolymers along with other materials such a Polyimide are continuing to provide higher dielectric strength while minimising arcing, allowing cables to deliver more power per unit mass. These innovations enable smaller, lighter wiring that fits within increasingly compact aircraft structures, extending flight range and improving overall performance.
High-voltage electrification introduces phenomena that were once secondary concerns. At altitude, reduced air pressure lowers dielectric breakdown thresholds, increasing susceptibility to corona discharge and partial discharge events. Even microscopic voids within insulation can initiate degradation over time.
For this reason, corona-resistant insulation systems such as polyimide andpolytetrafluoroethylene (PTFE) have become central to next-generation harness design, particularly in hybrid-electric propulsion and vertical take-off and landing aircraft. Ensuring compatibility with partial discharge limits is no longer optional but fundamental to airworthiness and long-term durability.
Materials, like polyimide or cross-linked ethylene tetrafluoroethylene (ETFE), also allow cables to withstand temperatures up to 260°C,while maintaining dielectric performance. This is vital for Unmanned Aerial Vehicles (UAVs) and Electric vertical take-off and landing aircraft (EVTOLs), which must operate in extreme environments like high altitudes.
Digital twins, virtual replicas of electrical systems are now playing a pivotal role in achieving these design breakthroughs. Engineers can simulate how a cable assembly behaves under different electrical loads, temperatures and vibration conditions before any physical prototype is built. This approach not only accelerates development but also ensures safety and compliance in the face of rising voltages and complex hybrid-electric architectures.
Precision manufacturing further refines this process. Robotics, AI-driven quality control and advanced extrusion technologies allow suppliers to achieve microscopic tolerances in conductor diameter, insulation thickness and shielding alignment. These refinements are essential for maintaining impedance, signal integrity and long-term reliability across an aircraft’s electrical network.
Managing heat, noise and weight
As systems become more electrified, engineers face an escalating challenge: controlling heat and electromagnetic interference (EMI) within ever-tighter packaging. Higher current densities increase heating and reduced space limits airflow, demanding innovative materials with superior thermal conductivity. New generations of polymer insulation not only withstand higher operating temperatures, but also enhance heat dissipation, keeping critical components stable even under peak loads.
Click image to enlarge
Meanwhile, EMI has become a defining concern. Foil-and-braid shielding, precise grounding and the separation of power and signal lines remain standard practice, but material science is taking these protections further. Aluminium and hybrid metal composites are replacing heavier traditional shielding, striking the ideal balance between conductivity and mass reduction.
Weight optimisation runs through every aspect of electrified design. Conductors are increasingly made from aluminium or specialised alloys to reduce density without sacrificing strength. Foamed fluoropolymers and air-inserted dielectric layers minimise material mass while preserving electrical integrity. In high-voltage environments, these refinements translate directly into improved endurance, range and payload capacity, a critical advantage for both military and commercial platforms.
Fibre optic integration is also changing how aircraft manage high-bandwidth communication. Compared with traditional copper cabling, fibre optic systems can reduce weight by up to 50 per cent in aerospace applications while supporting data rates in the gigabit range. Their inherent immunity to EMI removes the need for additional shielding layers, reducing both mass and energy losses associated with signal amplification.
Composite materials further influence connectivity decisions. Carbon fibre reinforced polymers used in modern airframes deliver substantial weight savings and offer higher specific strengths than aerospace-grade aluminium alloys.
Yet unlike aluminium skins, composites do not provide the same inherent, continuous electromagnetic shielding which increases reliance on cable-level shielding and bonding to meet standards such as MIL-STD-461.
As more aircraft platforms adopt composite fuselages, EMI control shifts from being partly inherent within the structure to being driven more by component and system design, particularly in UAVs and unmanned systems deployed across more testing conditions.
Adapting to new standards and materials
Electrification is reshaping not just design, but qualification itself. Standards such as UL 2556 and evolving Electrical Wiring Interconnection System (EWIS) requirements now push cables to withstand greater dielectric stress, thermal extremes and EMI exposure. These standards ensure aircraft wiring performs safely and reliably under demanding flight conditions. Manufacturers are responding with more rigorous testing and accelerated life-cycle simulations that mirror real environments.
The absence of unified high-voltage aviation standards has introduced additional complexity. Unlike traditional Mil-Spec frameworks that clearly define performance parameters, electrified aircraft architectures often require engineers to interpret progressing guidance from bodies such asSAE International and apply bespoke qualification criteria during development. This fragmentation can result in repeated electrical architecture revisions, placing pressure on both OEMs and suppliers to maintain flexibility and technical foresight throughout the programme lifecycle.
At the same time, growing scrutiny over per- and polyfluoroalkyl substances (PFAS), chemicals used in many fluoropolymer insulations has forced the industry to seek alternatives like polyimide, valued for its heat resistance and durability. However, qualifying these replacements takes years, making supply chain stability essential.
Supply chain resilience has therefore become inseparable from electrification strategy. Post-pandemic disruptions and geopolitical pressures have already demonstrated how component shortages can delay aircraft programmes for extended periods.
In an environment where design revisions are frequent and certification requirements continue to change, full visibility into suppliers, insulation systems and conductor availability is critical.
Early alignment between OEMs and authorised distributors reduces redesign risk and shortens validation cycles, ensuring electrified programmes maintain momentum rather than stall under logistical strain.
Click image to enlarge
Looking ahead, the next generation of aerospace cables will combine high-voltage tolerance, lightweight construction and embedded intelligence. Materials with built-in sensing could soon monitor temperature, strain and EMI in real time, while digital twins and AI-driven manufacturing set the stage for smarter, more connected flight systems.
Electrification is redefining every aspect of aerospace and defence engineering. From precision manufacturing to advanced insulation chemistry, success depends on materials that perform flawlessly in extreme environments.
It also depends on connectivity strategies that anticipate rising voltages, composite airframes and evolving regulatory expectations. As propulsion systems become more electric and aircraft architectures more data-centric, wiring ceases to be a supporting component and instead becomes a central enabler of safe, efficient flight.
WireMasters is leading this transformation with next-generation cabling solutions engineered for high-voltage, high-performance systems.
